Transparent screen iG LWT series is a newest all-in-one solution for smaLL businesses and window advertising. Transparent module and simple structure design make the appearance attractive to people.Any single LED strip could be replaced immediately. Any problem happened in LED strip could be solved within 1 minute. The power supply could be placed 30m away (Optional) and make the appearance simple and tidy. Easy and simple installation.
| Model | LWTG5 | LWTG8 | LWTG10 |
| Pixel Pitch (mm) | 5 x 8 | 7,5 x 8 | 10 |
| LED Model | SMD3528 | SMD3528 | SMD3528 |
| Brightness (nit) | 6000 | 6000 | 6000 |
| Viewing Angle (H/V) | 110°/110° | 110°/110° | 110°/110° |
| Viewing Distance (m) | 5 | 8 | 10 |
| Transparency | 68% | 68% | 75% |
| Module size (mm) | 960 x 1280 | 960 x 1280 | 960 x 1280 |
| Module resolution | 192 x 160 | 192 x 160 | 192 x 128 |
| Resolution (dot/㎡) | 25000 | 16666 | 10000 |
| Max. Power (W/panel) | 800 | 800 | 800 |
| Avg. Power (W/panel) | 240 | 240 | 240 |
| Signal type | DVI/HDMI | DVI/HDMI | DVI/HDMI |
| Brightness Adjustment | 256 | 256 | 256 |
| Gray Scale | 16 bit | 16 bit | 16 bit |
| Scan Duty | 1/4 | 1/3 | 1 |
| Ingress Protection | IP20 | IP20 | IP20 |
| Refresh rate (Hz) | 1000~1500 | 1000~1500 | 1000~1500 |
| Weight (kg/㎡, g/dot) | 18 kg/pcs | 18 kg/pcs | 18 kg/pcs |
| MTBF (hours) | > 10000 | > 10000 | > 10000 |
| Working Temp. (℃) | -10~40 | -10~40 | -10~40 |
